Surfer® 13

Overview Video

Surfer is a full-function contouring and surface modeling package that runs under Microsoft Windows. Surfer is used extensively for terrain modeling, bathymetric modeling, landscape visualization, surface analysis, contour mapping, watershed and 3D surface mapping, gridding, viewshed analysis, volumetrics, and much more.

Additional Info

  • Upgrade price: ($279 upgrade)
  • Sub heading: Powerful Contouring, Gridding, and 3D Surface Mapping Software for Scientists and Engineers
Quantity:
$849.00
back to top

Features

Surfer’s sophisticated interpolation engine transforms your XYZ data into publication-quality maps. Surfer provides more gridding methods and more control over gridding parameters, including customized variograms, than any other software package on the market. You can also use grid files obtained from other sources, such as USGS DEM files or ESRI grid files. Display your grid as outstanding contour, 3D surface, 3D wireframe, watershed, vector, image, shaded relief, and viewshed maps. Add base maps to show boundaries and imagery, post maps to show point locations, and combine map types to create the most informative display possible. Virtually all aspects of your maps can be customized to produce exactly the presentation you want. Generating publication quality maps has never been quicker or easier.

Who should use Surfer?

Hydrologists, engineers, geologists, archeologists, oceanographers, biologists, foresters, geophysicists, medical researchers, climatologists...

Features Tour

Surfer Contour MapContour Maps

Surfer contour maps give you full control over all map parameters. You can accept the Surfer intelligent defaults to automatically create a contour map, or double-click a map to easily customize map features.


Read More

Surfer 3D Surface Map3D Surface Maps

The 3D surface map uses shading and color to emphasize your data features. Change the lighting, display angle and tilt with a click of the mouse. Overlay several surface maps to generate informative block diagrams.


Read More

Surfer Image Map - Color GradationImage Maps

Image maps use different colors to represent Z values of a grid file. Surfer automatically blends colors between Z values so you end up with a smooth color gradation over the entire map.


Read More

Surfer Post MapPost Maps

Post maps show points at XY locations, such as sample locations, well locations, or original data point locations. Use the points to show the distribution of data points on the map, and to demonstrate the accuracy of the gridding methods you use.


Read More

Surfer Base MapsBase Maps

Surfer can import maps in many different formats to display geographic information. Base maps are created from any number of file formats, such as SHP, DXF, GeoTIFF, and PDF.


Read More

Surfer Shaded Relief MapShaded Relief Maps

Shaded relief maps are raster images based on grid files. Colors are assigned based on slope orientation relative to a light source. Surfer determines the orientation of each grid cell and calculates reflectance of a point light source on the grid surface.


Read More

Surfer Wireframe Map3D Wireframe Maps

Surfer wireframe maps provide an impressive three dimensional display of your data. Wireframes are created by connecting Z values along lines of constant X and Y.


Read More

Surfer Vector MapVector Maps

Instantly create vector maps in Surfer to show direction and magnitude of data at points on a map. You can create vector maps from information in one grid or two separate grids. The two components of the vector map, direction and magnitude, are automatically generated from a single grid by computing the gradient of the represented surface.


Read More

Surfer Watershed MapWatershed Maps

Watershed maps automatically calculate and display drainage basins and streams from your grid file.


Read More

Surfer Viewshed MapViewshed Maps

Perform viewshed analysis using a loaded grid file with a user-specified transmitter location, height, starting angle and radius. All visible areas from the transmitter location within the selected radius are filled with a user-specified color.


Read More

Surfer ProfilesProfiles

Surfer's automatic profile tool makes it easy to visualize the change in Z value from one point to another.


Read More

Surfer Graticule MapGraticule and Grid Lines

Add graticule lines or another grid to your map to view the location in multiple sets of coordinate units!  Display latitude and longitude graticule lines over a projected map, or create a map in meters and add a grid in feet.


Read More

Surfer Geoprocessing ToolsGeoprocessing Tools

Many geoprocessing tools are available for you to edit your vector features the way you need. Some uses for geoprocessing tools include reshaping features to a new shape, creating buffer polygons or setbacks, simplifying or smoothing features, and calculating intersections between overlapping polygons.


Read More

Surfer Coordinate Systems MapCoordinate Systems

Choose from an endless list of coordinate systems for your map to display. Specify the source coordinate system for each of the layers in your map, and choose to display the map in any other coordinate system! For example, load data and grid files in UTM or State Plane coordinates, and display the map in Latitude/Longitude coordinates! It is simply that easy!


Read More

Surfer Map LayersMap Layers

Adding multiple map layers to your map gives you a way to combine different types of data in one map. For example, you can drape a georeferenced image over a 3D surface map, overlay multiple base maps with a contour map, or plot a post map with contours over a wireframe map.


Read More

Surfer Stacking MapStacking Maps

You can align individual maps horizontally on the page by stacking them. Map stacking was designed to align maps using commensurate coordinate systems. This command is useful for keeping two or more maps separated vertically on the page while keeping relative horizontal positions.


Read More

Surfer CustomizationCustomize Your Map

Make your map look its best by customizing it to fit your needs! Surfer offers numerous map features to enhance the look of your map. Use Surfer’s defaults, or customize your map by including scale bars, editing colors, lines and fill styles, showing only portions of a map, adjusting the scale and setting axis properties!


Read More

Surfer Superior GriddingSuperior Gridding

The gridding methods in Surfer allow you to produce accurate contour, surface, wireframe, vector, image, watershed, viewshed and shaded relief maps from your XYZ data. The data can be randomly dispersed over the map area, and Surfer's gridding will interpolate your data onto a grid. Use Surfer’s default settings or choose from twelve different gridding methods.


Read More

Surfer VariogramsVariograms

Use the variogram modeling subsystem to quantitatively assess the spatial continuity of data. Variograms may be used to select an appropriate variogram model when gridding with the Kriging algorithm. Surfer uses a variogram grid as a fundamental internal data representation and once this grid is built, any experimental variogram can be computed instantaneously.


Read More

Surfer Faults MapFaults and Breaklines

Define faults and breaklines when gridding your data. Faults act as barriers to the information flow, and data on one side of the fault will not be directly used to calculate grid node values on the other side of the fault. Breaklines include Z values.


Read More

Surfer Grid Node EditorGrid Node Editor

Clean up your grid with the grid node editor!


Read More

Surfer Grid FunctionGrid Functions

In addition to creating maps, you can perform a variety of functions using grid files. Just a few of the possibilities include:


Read More

Surfer and USGS DataUsing USGS and SRTM Data

Use USGS Digital Elevation Model (DEM), National Elevation Dataset (NED) and NASA Shuttle Radar Topographic Mission (SRTM) data with any Surfer command that uses grid files.


Read More

Surfer WorksheetWorksheet

Surfer lets you massage your data in many ways to achieve the exact output you want. Surfer includes a full-featured worksheet for creating, opening, editing, and saving data files. Data files can be up to one billion rows and columns, subject to available memory. You can cut, copy, and paste data within the Surfer worksheet or between applications.


Read More

Surfer Object and Property ManagerObject and Property Manager

The object manager and property manager makes the editing of any object simple. The object manager displays all the objects in the plot document in an easy-to-use hierarchical tree arrangement.


Read More

automationAutomation

Create your own scripts to automate repetitive tasks! Don’t spend time doing the same process over and over again – write a simple script to simplify your life! Operations performed interactively can be controlled using an automation-compatible programming language such as Visual Basic, C++, python or perl.


Read More

Surfer KML Export to Google EarthAdditional Features

Your Surfer package comes with many additional features to help you work smarter, not harder!


Read More

Surfer Supported File FormatsSupported File Formats

Surfer supports many data, grid, and import/export formats.


Read More

FAQs

Q1. What is the latest version?
Q2. How can I get the latest version of Surfer?
Q3. Where can I find a list of fixes and changes between versions?
Q4. What are Surfer’s system requirements?
Q5. How do I install Surfer?
Q6. How do I uninstall Surfer?
Q7. Should I uninstall the demo version before installing the full version, or can I activate the demo to become the full version?
Q8. Do I need to uninstall an older version of Surfer before installing a new version?
Q9. Do you offer training?
Q10. Where can I find my serial number?
Q11. Is technical support free?
Q12. Is there a 64-bit version available?
Q13. Should I install Surfer 32-bit or Surfer 64-bit?
Q14. What is the SRF file compatibility between different versions of Surfer?
Q15. What are the terms of the Golden Software End User License Agreement?
Q16. I have a more technical question about the program, where can I find the answer?

Q1. What is the latest version?
A. The most recent version of Surfer is 13.4.553.

Q2. How can I get the latest version of Surfer?
A. Minor updates (e.g. version 13.0 to 13.4) may be downloaded for free if your serial number is registered. Connect your computer to the Internet, then go to Help | Check for Update in Surfer. This will download the latest patch and install it on your machine. Information about the latest version is listed on the Version History page.

If you experience any problems with this command or would like to download the full version of the updated software, please email your registered Surfer serial number to surfersupport@goldensoftware.com. Once your serial number is verified, we will send you download instructions.

Major upgrades (i.e. version 12 to version 13) cost US$279 plus shipping. Refer to the order form for more information.

Q3. Where can I find a list of fixes and changes between versions?
A. A list of changes and fixes between minor versions (e.g. 13.0 to 13.4) can be found on the Version History page.

Q4. What are Surfer’s system requirements?
A. Surfer’s system requirements are here.

Q5. How do I install Surfer?
A. Installing Surfer requires that you be logged into an account that has Administrator rights. Golden Software does not recommend installing Surfer 13 over any previous version of Surfer. Please ensure that you install Surfer 13 into a new directory, which is what will happen by default. Surfer 13 can co-exist with older versions as long as they are in different directories.

To begin the installation, either insert the CD into the CD-ROM drive, or double-click on the downloaded EXE file to run it. See below for details of each method.

Installing Surfer on a Local Drive from CD:

  1. Insert the CD-ROM in the CD-ROM drive. The Setup program automatically begins on most computers.
  2. Choose the "Install Surfer" option from the screen and setup will begin.

If the Setup program does not automatically start, double-click on the My Computer icon on your desktop. Open the CD-ROM drive which contains the Surfer disk by double-clicking on the CD-ROM icon. From the CD-ROM folder find and double-click on Autorun.exe to launch Surfer's Setup program. Select the "Install Surfer" option and setup will begin.

Installing Surfer on a Local Drive Using a Downloaded EXE:

  1. Double-click on the My Computer icon on your desktop and navigate to the folder containing the downloaded file.
  2. Double-click the downloaded file to begin the installation process.

Q6. How do I uninstall Surfer?
A. To uninstall Surfer:

Windows XP
To uninstall Surfer, go to the Control Panel and double click on Add/Remove Programs. Select “Surfer 13" (or “Surfer Demo 13” for the demo version) from the list of installed applications. Click the Remove button to uninstall Surfer.

Windows Vista
To uninstall Surfer when using the Regular Control Panel Home, click the Uninstall a program link. Select “Surfer 13” (or “Surfer Demo 13” for the demo version) from the list of installed applications. Click the Uninstall button to uninstall Surfer.

To uninstall Surfer when using the Classic View, go to the Control Panel and double click on Programs and Features. Select “Surfer 13” (or “Surfer Demo 13” for the demo version) from the list of installed applications. Click the Uninstall button to uninstall Surfer.

Windows 7
To uninstall Surfer, go to the Control Panel and click the Uninstall a program link. Select “Surfer 13” (or “Surfer Demo 13” for the demo version) from the list of installed applications. Click the Uninstall button to uninstall Surfer.

Windows 8
From the Start screen, right-click the Surfer 13 tile and click the Uninstall button at the bottom of the screen. Alternatively, right-click anywhere on the Start screen and click All apps at the bottom of the screen. Right-click the Surfer 13 tile and click Uninstall at the bottom of the screen.

Q7. Should I uninstall the demo version before installing the full version, or can I activate the demo to become the full version?
A. Yes, you should uninstall the Surfer demo before installing the full version of Surfer. There is not a way to “activate” the demo version to become the full version.

Q8. Do I need to uninstall an older version of Surfer before installing a new version?
A. You do not need to uninstall previous versions of Surfer (i.e. Surfer 10) before installing Surfer 13, provided you install them in different directories. By default, this will be the case.

You do not need to uninstall a previous version of Surfer 13 before installing an updated version of Surfer 13, as the installation package will automatically do this for you.

Q9. Do you offer training?
A. Golden Software will occasionally offer live training courses. Visit our Training Classes page to view scheduled classes.

Golden Software does offer a variety of Free Training Resources. Please use the following links to learn more about Surfer.

  1. Surfer Videos and Webinars
  2. Surfer Forum
  3. Product Tutorials available in Surfer - click Help | Tutorial
  4. Surfer's online Knowlege Base
  5. Golden Software Newsletters
  6. Golden Software Blog articles about Surfer
  7. Surfer Scripts
  8. Surfer FAQs
  9. Surfer Tech Support Email
  10. Surfer Tech Support Phone:  303-279-1021 Golden Software, Inc. business hours are 8:00 AM to 5:00 PM Mountain Time Monday through Friday (excluding U.S. holidays)
  11. Full Users Guide can be purchased for $25USD

Q10. Where can I find my serial number?
A. The serial number is located on the CD sleeve, or in the download instructions you received when you ordered the software. Please register your serial number online. After you install Surfer and run it for the first time, you can also find your serial number by opening the software and going to Help | About Surfer. The About Surfer dialog box will show the serial number. You can also log in to your Golden Software user account to view your serial number.

Q11. Is technical support free?
A. Yes, technical support is free to all users for as long as you own the product. You must register your product in order to receive technical support. Technical support is available by phone, fax, or email. Contact us.

Q12. Is there a 64-bit version available?
A. Yes, Surfer comes as a 32-bit application and as a 64-bit application.

Q13. Should I install Surfer 32-bit or Surfer 64-bit?
A.
If you are using a 32-bit version of Windows, then Surfer 32-bit is installed automatically.

If you are using a 64-bit version of Windows, then Surfer 64-bit will be installed automatically. There is an option to install the 32-bit version instead, but we recommend installing the 64-bit version of Surfer. Although Surfer 32-bit is capable of installing and running on Windows 64-bit, the 32-bit version does not take advantage of the increased 64-bit memory space.

Q14. What is the SRF file compatibility between different versions of Surfer?
A.
Surfer 13 can open SRF files created in Surfer versions 7 through 13. If you have an SRF file created in an earlier version, please zip and email it to surfersupport@goldensoftware.com so it can be converted to the newer format for Surfer.

Surfer 13 can save SRF files in the Surfer 13, 12 and Surfer 11 SRF format to be opened by those versions, respectively.

Q15. What are the terms of the Golden Software End User License Agreement?
A. The full details of the End User License Agreement (EULA) may be found at http://www.goldensoftware.com/home/terms-of-use. The salient points of the EULA are as follows:

  • All Golden Software licenses are single user licenses, where a user is a person and not a machine.
  • Licenses may not be shared among multiple users.
  • Network installation is allowed, as long as a separate license is purchased for each individual user who will access the network install. For instance, if 4 different users plan to access the software, 4 individual licenses must be purchased.
  • Software may only be used on one computer at any time.
  • Software may be installed on multiple computers (i.e. home, office desktop, and field laptop), as long as only the licensed user accesses the software on any of the computers.
  • One (1) copy of the software and one (1) copy of the user documentation maybe be made for backup purposes only.
  • License may be transferred to another user by the registered user contacting the Golden Software sales department.
  • After a license is transferred to another user, the original user must uninstall the software from all machines they had it installed on. Any copies on original user’s hard-disk drive(s) or back-up media must also be destroyed.
  • After a license is upgraded to a newer version, the older software must be uninstalled. Any older version CDs, serial numbers, or backup copies on hard-disk drive(s) or back-up media must be destroyed within sixty (60) days of the upgrade.

Q16. I have a more technical question about the program, where can I find the answer?
A. For more technical questions and answers, please visit our Knowledge Base.

Case Studies

  • Complex Data Made Clear with Surfer

    Marine data is typically be gathered over time. Traditional 2D and 3D visualization techniques for time series data is not always adequate. Dr. Richard Koehler demonstrates a new way to model this complex data.
  • Identifying Ore Deposits using Lineament Analysis with Surfer

    Ricardo Valls combines lineament analysis, geophysics, geology, and geochemisty in Colombia to identify the next big emerald ore deposit...
  • Modeling Groundwater Resources in Surfer

    Characterizing groundwater resources is a critical step when analyzing potential mining areas. Knight Piésold characterized groundwater resources for decommissioned gold and silver mine in preparation for permitting future mining scenarios...
  • Geophysical Survey of the Barton Springs Pool Austin, Texas

    Mustafa Saribudak, founder of Environmental Geophysics Associates, recently located a new fault in the Edwards Aquifer region as they were surveying the Barton Springs Pool…
  • Surfer Aids in Search for Missing Anchor

    A ship traveling through a Netherlands estuary was required to drop anchor among electrical cables and pipelines transporting gasoline and chemicals due to an emergency. Forced to cut and then leave the anchor behind, Henk de Vries takes on the challenge of retrieval...
  • Using Surfer to Create "Temporal Maps"

    Richard Koehler observes the behavior of adult Chinook salmon swimming upstream on the Columbia River with the versatility of Surfer to create a time map using two temporal coordinates...
  • Surveying Archaeological Tel Sites in the Homs Region

    While Rob Golding was employed as a field archaeologist for Wessex Archaeology he was invited to travel to Syria and survey archaeological sites within the Homs region...
  • Geochemical Mapping of Urban and Suburban Areas

    Alecos Demetriades continuously gives back to geochemists across the globe. He recently published a textbook and manual on mapping the chemical environment of urban areas...
  • Visualization Techniques to Get the Most Out of Your Data

    T/X Resources' President discusses powerful geoscience tools and techniques in order to get the most out of data visualization for geophysical consulting...
